The CEF500100GX is a high-quality marine impeller designed for seawater pump applications in marine diesel and petrol engines. It ensures consistent water flow for proper engine cooling and reliable operation under demanding marine conditions.
Manufactured from durable marine-grade neoprene, this impeller offers excellent flexibility, wear resistance and long service life.
Designed as a direct replacement for multiple OEM part numbers across leading marine engine and pump brands.
Technical Specifications
Number of Blades: 6
Outer Diameter (Ø): 39.6 mm
Width: 18.94 mm
Shaft Diameter: 9.54 mm
Material: Marine-grade neoprene
Application: Seawater cooling pump
These dimensions must match your existing impeller to ensure correct fitment.
Replaces OEM Part Numbers
Volvo Penta
3580029 3586494 803729 807369 833550 875807 876689
Yanmar
104211-42070
Perkins
24880272
Sherwood
09979 9979K
Johnson Pump
09-806B 09-806B-1
Jabsco
4528-0001 4528-0001-P 4528-0003 4528-0003-P
Onan
132-0859
Nanni
434014
Bukh
610G0102
Engine Compatibility
Volvo Penta
MD1A MD1B MD2A MD2B MD3B MD6A MD7A MD7B MB10A AQD2B MD2010 MD2020
Yanmar
2GM 2GM20 3GM 3GM30 2QM15 YSB8 YSB12 YSE8 YSE12 YSM7
Perkins
Perama M20
Nanni
FK2 2.60H
Onan
Selected marine generator models using impeller 132-0859
Key Features
Precision-molded 6-blade design
Accurate OEM-equivalent dimensions
Wide cross-brand compatibility
Resistant to saltwater and heat
Suitable for routine maintenance or emergency replacement
Maintenance Recommendation
Impellers should typically be replaced annually or approximately every 200 operating hours, depending on operating conditions. Running a pump dry, sand ingestion, or long idle periods can significantly reduce impeller lifespan.
Regular preventive replacement helps avoid overheating and protects the engine cooling system.
Fitment Support
Before ordering, verify:
Outer diameter: 39.6 mm
Width: 18.94 mm
Shaft diameter: 9.54 mm
Blade count: 6
If unsure, contact us with your engine model or pump reference for confirmation.
